Peugeot offers a range of versatile vans—Bipper, Boxer, Expert, and Partner—designed to suit all types of commercial needs. Each model provides distinct configurations and dimensions, making them ideal for different industries. Whether you’re seeking a compact van like the Bipper for urban deliveries or a spacious model like the Boxer for heavy-duty transportation, understanding the specifications and dimensions of each model is crucial for selecting the right van.
This comprehensive guide covers the key dimensions and configurations of these Peugeot vans, ensuring you have a detailed understanding before choosing a model and accessories.
Peugeot Bipper Van Dimensions
The Peugeot Bipper Van, launched in 2008, is a versatile and compact commercial vehicle perfect for navigating urban environments. With its practical size, the Bipper is ideal for small businesses and light-duty applications, offering efficient cargo space and manoeuvrability. Below are detailed tables highlighting the dimensions, load capacity, and internal space of the Peugeot Bipper, particularly the L1H1 twin-door model.
For more information on Peugeot Bipper Van accessories including Van racking that can maximise space in your van visit Vanify. We offer OS Van Racking and NS Van Racking.
| Specification | Measurement |
|---|---|
| Length | 3,864 mm |
| Width (body) | 1,684 mm |
| Width (with mirrors) | 2,019 mm |
| Height | 1,721 mm |
| Wheelbase | 2,513 mm |
| Ground Clearance | 170 mm |
Peugeot Bipper L1H1 Twin Doors Dimensions
The Peugeot Bipper L1H1 Twin Doors model is designed for urban use, providing excellent manoeuvrability combined with efficient load space. The twin rear doors offer easy access to cargo, making it suitable for businesses requiring frequent loading and unloading in tight spaces.
Below are the detailed dimensions for the load space, payload capacity, and door measurements of the L1H1 twin-door configuration.
Load Space Dimensions
| Specification | Measurement |
|---|---|
| Load Length | 1,523 mm (extendable to 2,491 mm with fold-flat seat) |
| Load Width (maximum) | 1,473 mm |
| Load Width (between wheel arches) | 1,046 mm |
| Load Height | 1,178 mm |
| Cargo Volume | 2.5 m³ (expandable to 2.8 m³) |
Payload and Weight Specifications
| Specification | Measurement |
|---|---|
| Gross Vehicle Weight | 1,610 - 1,630 kg |
| Payload Capacity | Up to 610 kg |
Door Dimensions
| Door Type | Measurement |
|---|---|
| Rear Door Height | 1,060 mm |
| Rear Door Width | 1,140 mm |
| Side Door Height | 1,041 mm |
| Side Door Width | 644 mm |
Peugeot Boxer Van Dimensions
The Peugeot Boxer Van, spanning model years from 1994 to 2006 and beyond, offers a range of configurations, including L1H1, L1H2, L2H1, L2H2, L3H2, and L4H2. These configurations vary in load space, payload capacity, and external dimensions, making the Boxer an adaptable option for various commercial needs. Below are the comprehensive dimensions for Boxer models and accessories:
Interior Dimensions (mm)
| Configuration | Volume (m³) | Load Length at Floor | Load Height (Max) | Load Width (Max) | Load Width (Between Arches) | Side Door Width | Rear Door Width | Rear Door Height |
|---|---|---|---|---|---|---|---|---|
| L1H1 | 8 | 2,670 | 1,662 | 1,870 | 1,422 | 1,075 | 1,562 | 1,520 |
| L1H2 | 10 | 3,120 | 1,932 | 1,870 | 1,422 | 1,250 | 1,562 | 1,790 |
| L2H1 | 10 | 3,120 | 1,662 | 1,870 | 1,422 | 1,250 | 1,562 | 1,520 |
| L2H2 | 11.5 | 3,120 | 1,932 | 1,870 | 1,422 | 1,250 | 1,562 | 1,790 |
| L3H2 | 13 | 3,705 | 1,932 | 1,870 | 1,422 | 1,250 | 1,562 | 1,790 |
| L4H2 | 15 | 4,070 | 1,932 | 1,870 | 1,422 | 1,250 | 1,562 | 1,790 |
Exterior Dimensions (mm)
| Configuration | Wheelbase | Length | Height | Width (Excl. Mirrors) | Front Overhang | Rear Overhang |
|---|---|---|---|---|---|---|
| L1H1 | 3,000 | 4,963 | 2,254 | 2,050 | 948 | 1,015 |
| L1H2 | 3,450 | 5,413 | 2,522 | 2,050 | 948 | 1,015 |
| L2H1 | 3,450 | 5,413 | 2,254 | 2,050 | 948 | 1,015 |
| L2H2 | 3,450 | 5,413 | 2,522 | 2,050 | 948 | 1,015 |
| L3H2 | 4,035 | 5,998 | 2,522 | 2,050 | 948 | 1,015 |
| L4H2 | 4,035 | 6,363 | 2,522 | 2,050 | 948 | 1,380 |
Peugeot Boxer L1H1 Dimensions
The Peugeot Boxer L1H1 model is the smallest configuration in the Boxer range, designed to offer efficient cargo space while maintaining compact exterior dimensions for urban driving. For a more detailed look on Peugeot Boxer Van accessories including rear ladders, seat covers, and roof bars visit Vanify.
Below is a detailed breakdown of its load area dimensions and interior specifications:
Load Area Dimensions (mm)
| Specification | Measurement |
|---|---|
| Cargo Volume | 8 m³ |
| Load Length at Floor | 2,670 mm |
| Load Length at Mid-Height with Bulkhead | 2,464 mm |
| Load Width (Maximum) | 1,870 mm |
| Load Width (Between Wheel Arches) | 1,422 mm |
| Load Height (Maximum) | 1,662 mm |
| Rear Door Width | 1,562 mm |
| Rear Door Height | 1,520 mm |
| Side Door Width | 1,075 mm |
| Side Door Height | 1,485 mm |
| Load Sill Height | 535-565 mm |
Peugeot Boxer L3H2 and L4H2 Dimensions
The Peugeot Boxer L3H2 and L4H2 models are part of the long-wheelbase range, designed to offer expanded cargo space for larger loads. Both configurations provide significant capacity but differ in overall length and load space. Below is a comparison of the key dimensions for the L3H2 and L4H2 models, focusing on cargo space and long-wheelbase capacity.
Peugeot Boxer L3H2 Dimensions
| Specification | Measurement |
|---|---|
| Cargo Volume | 13 m³ |
| Load Length at Floor | 3,705 mm |
| Load Width (Maximum) | 1,870 mm |
| Load Width (Between Wheel Arches) | 1,422 mm |
| Load Height (Maximum) | 1,932 mm |
| Rear Door Width | 1,562 mm |
| Rear Door Height | 1,790 mm |
| Side Door Width | 1,250 mm |
| Side Door Height | 1,755 mm |
| Wheelbase | 4,035 mm |
| Overall Length | 5,998 mm |
| Overall Height | 2,522 mm |
| Load Sill Height | 535-565 mm |
Peugeot Boxer L4H2 Dimensions
| Specification | Measurement |
|---|---|
| Cargo Volume | 15 m³ |
| Load Length at Floor | 4,070 mm |
| Load Length at Mid-Height with Bulkhead | 3,920 mm |
| Load Width (Maximum) | 1,870 mm |
| Load Width (Between Wheel Arches) | 1,422 mm |
| Load Height (Maximum) | 1,932 mm |
| Rear Door Width | 1,562 mm |
| Rear Door Height | 1,790 mm |
| Side Door Width | 1,250 mm |
| Side Door Height | 1,755 mm |
| Wheelbase | 4,035 mm |
| Overall Length | 6,363 mm |
| Overall Height | 2,522 mm |
| Load Sill Height | 535-565 mm |
Key Differences Between L3H2 and L4H2:
- Cargo Volume: The L3H2 offers a cargo volume of 13 m³, while the L4H2 provides a larger volume of 15 m³, making it more suitable for transporting large loads.
- Load Length: The L3H2 has a load length of 3,705 mm, whereas the L4H2 extends to 4,070 mm, giving you an extra 365 mm of load space.
- Overall Length: The L3H2 is 5,998 mm long, compared to the 6,363 mm length of the L4H2, meaning the L4H2 offers more total space but is also longer, impacting manoeuvrability in tight spaces.
Peugeot Expert Van Dimensions
The Peugeot Expert Van (2007-2016+) offers multiple configurations, including L1H1, L2H1, and L2H2 variations, making it suitable for various commercial needs. Below is a detailed breakdown of the dimensions for these models, with a focus on cargo space, interior capacity, and door specifications for twin-door and tailgate versions.
Peugeot Expert L1H1, L2H1, and L2H2 Dimensions
| Specification | L1H1 | L2H1 | L2H2 |
|---|---|---|---|
| Cargo Volume | 5.3 m³ | 6.1 m³ | 6.6 m³ |
| Load Length at Floor | 2,512 mm | 2,862 mm | 2,862 mm |
| Load Length with MODUWORK® | 3,324 mm | 4,024 mm | 4,024 mm |
| Load Width (Maximum) | 1,628 mm | 1,628 mm | 1,628 mm |
| Load Width (Between Wheel Arches) | 1,258 mm | 1,258 mm | 1,258 mm |
| Load Height (Maximum) | 1,397 mm | 1,397 mm | 1,397 mm |
| Side Door Width | 935 mm | 935 mm | 935 mm |
| Side Door Height | 1,238 mm | 1,241 mm | 1,241 mm |
| Rear Door Width | 1,282 mm | 1,282 mm | 1,282 mm |
| Rear Door Height | 1,220 mm | 1,220 mm | 1,220 mm |
| Overall Length | 4,609 mm | 4,959 mm | 5,309 mm |
| Wheelbase | 2,925 mm | 3,275 mm | 3,275 mm |
| Overall Height (1000kg model) | 1,910 mm | 1,899 mm | 1,940 mm |
| Overall Height (1400kg model) | 1,950 mm | 1,940 mm | 1,940 mm |
Peugeot Expert L1H1 Dimensions
The Peugeot Expert L1H1 model is the compact variant of the Expert range. It is designed to balance cargo capacity and ease of manoeuvrability, especially in urban environments. Below are the detailed specifications focusing on the load space and internal capacity for the L1H1 model.
Peugeot Expert L1H1 Load Space Dimensions
| Specification | Measurement |
|---|---|
| Cargo Volume | 5.3 m³ |
| Load Length at Floor | 2,512 mm |
| Load Length with MODUWORK® | 3,324 mm |
| Load Width (Maximum) | 1,628 mm |
| Load Width (Between Wheel Arches) | 1,258 mm |
| Load Height (Maximum) | 1,397 mm |
Door Dimensions
| Specification | Measurement |
|---|---|
| Side Door Width | 935 mm |
| Side Door Height | 1,238 mm |
| Rear Door Width | 1,282 mm |
| Rear Door Height | 1,220 mm |
External and Internal Dimensions
| Specification | Measurement |
|---|---|
| Wheelbase | 2,925 mm |
| Overall Length | 4,609 mm |
| Overall Height | 1,910 mm (1000kg model), 1,950 mm (1400kg model) |
| Width (Excluding Mirrors) | 1,920 mm |
| Width (Including Mirrors) | 2,204 mm |
| Front Overhang | 881 mm |
| Rear Overhang | 803 mm |
Peugeot Partner Van Dimensions
The Peugeot Partner Van (2008-2018) comes in two primary configurations: L1H1 (short wheelbase) and L2H1 (long wheelbase). Both options are available with either tailgate or twin rear doors, making them flexible for different business needs. Below is an overview of the dimensions for these configurations, with a focus on load space, internal capacity, and door specifications.
| Specification | L1H1 (Short Wheelbase) | L2H1 (Long Wheelbase) |
|---|---|---|
| Cargo Volume | 3.3 m³ | 3.8 m³ |
| Cargo Volume with Multi-Flex® | 3.9 m³ | 4.4 m³ |
| Load Length at Floor | 1,817 mm | 2,167 mm |
| Load Length with Multi-Flex® | 3,090 mm | 3,440 mm |
| Load Width (Maximum) | 1,550 mm | 1,550 mm |
| Load Width (Between Wheel Arches) | 1,229 mm | 1,229 mm |
| Load Height | 1,236 mm | 1,243 mm |
| Side Door Width (Min-Max) | 641 mm - 675 mm | 641 mm - 675 mm |
| Side Door Height | 1,072 mm | 1,072 mm |
| Rear Door Width | 1,241 mm | 1,241 mm |
| Rear Door Height | 1,196 mm | 1,196 mm |
| Rear Sill Height (Min-Max) | 548-586 mm | 571-610 mm |
| Overall Length | 4,403 mm | 4,753 mm |
| Overall Height | 1,840 mm | 1,840 mm |
| Overall Width (without mirrors) | 1,848 mm | 1,848 mm |
| Overall Width (with mirrors) | 2,107 mm | 2,107 mm |
Peugeot Partner L1H1 Dimensions
The Peugeot Partner L1H1 (short wheelbase, low roof) is a compact commercial van that offers a practical balance between load capacity and manoeuvrability, making it ideal for urban deliveries. Below is a detailed breakdown of the load space dimensions and payload capacity for the L1H1 model.
Peugeot Partner L1H1 Load Space Dimensions
| Specification | Measurement |
|---|---|
| Cargo Volume | 3.3 m³ |
| Cargo Volume with Multi-Flex® | 3.9 m³ |
| Load Length at Floor | 1,817 mm |
| Load Length with Multi-Flex® | 3,090 mm |
| Load Width (Maximum) | 1,550 mm |
| Load Width (Between Wheel Arches) | 1,229 mm |
| Load Height (Maximum) | 1,236 mm |
Door Dimensions
| Specification | Measurement |
|---|---|
| Side Door Width (Min-Max) | 641 mm - 675 mm |
| Side Door Height | 1,072 mm |
| Rear Door Width | 1,241 mm |
| Rear Door Height | 1,196 mm |
Payload Capacity
| Specification | Measurement |
|---|---|
| Max Payload | Up to 1,000 kg |
| Rear Sill Height | 548-586 mm |
Key Features:
- Multi-Flex® System: The load length can be extended from 1,817 mm to 3,090 mm using the Multi-Flex® foldable passenger seat, increasing cargo volume from 3.3 m³ to 3.9 m³.
- Payload Capacity: The Peugeot Partner L1H1 can handle a payload of up to 1,000 kg, making it highly versatile for transporting goods and equipment.
- Compact Design: With an overall length of 4,403 mm and a maximum width (excluding mirrors) of 1,848 mm, the L1H1 model is well-suited for city driving and navigating tight spaces while still offering significant cargo capacity.
